knobkit

CI npm version license

Your AI app, live as you type. Declare widgets, write on(event, handler) functions — done. The same demo.tsx runs entirely in the browser (mount) or on a stateless Node server (serve); change the last line to swap. The browser owns all state — the server keeps none, so there are no sessions.

knobkit.dev — 30-second tour + a live playground (nothing to install).

🛠️ Building with an AI agent? The knobkit-skills Agent Skill is the recommended way to scaffold and build a knobkit app fast — works in Claude Code or any Agent Skills–compatible agent.

knobkit — scaffold, run the dev server, edit, watch the browser update live

import { knobkit, mic, output } from "knobkit";
import { pipeline } from "@huggingface/transformers";

const transcriber = await pipeline("automatic-speech-recognition", "onnx-community/whisper-base.en");
const recorder = mic();
const transcript = output();

const app = knobkit({ title: "Transcribe", widgets: [recorder, transcript] });

app.on(recorder.clip, async (samples) => {
  const { text } = (await transcriber(samples)) as { text: string };
  transcript.set(text.trim() || "(silence)");
});

app.serve(); // runs Whisper on Node — change to app.mount("#root") to run it in the browser via WebGPU

See examples/ — chatbots, image captioning, live transcription, webcam filters; each a single demo.tsx.

Quick start

npm create knobkit@latest my-app   # prompts mount (browser) vs serve (node); or pass --mount / --serve
cd my-app && npm install && npm run dev

Already have a project? npm install knobkit. Requires Node ≥ 22.

CLI

knobkit dev         # dev server — auto-detects the tier from mount()/serve() in the entry
knobkit build       # build a mount app to static files in dist/
knobkit serve       # run a serve app
knobkit playground  # split-pane REPL: editor + live preview, file picker, edits round-trip to disk

Entry = your package.json "main" (override with knobkit dev other.tsx). --mount / --serve force the tier; --port <n> sets the port (playground default 4317).

How it works

A handler is a plain on(event, async fn). Inside it you do exactly three things:

  • read widget state with async getters — await box.value(), await convo.history() (a real round-trip on serve);
  • write with structured setters — out.set(v), convo.say(m), log.push(line);
  • produce by returning an event from the handler (re-emitted, like a user action).

setup(fn) runs once per session for async startup (load weights, fetch data). widget.busy(fn) wraps a handler in a transient working span (a bar; drops the widget's input while running); disable() / enable() is the persistent version. Widget methods only work inside a handler or setup.

mount("#root") serve()
on(...) handlers run in the browser run on a stateless Node server
transport local call socket.io
use when fits client-side (incl. WebGPU models) needs the server (large models, secrets, native deps)

mount builds to static files you can host anywhere; serve adds no session state. Widgets, handlers, and methods are identical across both — only the last line changes.

Widgets

Value inputs all share one shape: a changed event whose payload is the value, plus await w.value() and w.set(v). (No .submitted/.uploaded — listen on changed, or use a button's .clicked and read await input.value().)

Factory (defaults) changed value Notes
text({ placeholder?, lines? }) string lines = textarea rows (default 1)
number({ value?, min?, max? }) number numeric stepper (init 0)
slider({ value?, min?, max?, step? }) number min 0, max 100, step 1
dropdown({ choices, value? }) string choices: string[]; value defaults to choices[0]
checkbox({ label?, value? }) boolean single toggle
checkboxGroup({ choices, value? }) string[] multi-select
radio({ choices, value? }) string single-select
upload({ accept? }) string | null value is a data URL; accept default image/*

Other inputs:

Factory (defaults) Events Methods
button({ label }) clicked set({ label })
mic({ every?, control?, hold? }) clip (Float32Array), toggled start(), stop(), await toggle(), await live(). every ms emits a clip every N ms (0 = hold/toggle only)
webcam({ every?, control?, preview?, facing? }) frame (data URL), toggled same controls. every ms emits a frame every N ms (0 = preview only); facing "user"/"environment"
chat({ placeholder?, voice?, images?, markdown? }) sent ({ text, image? }), recorded await history(), say(msg), append(token). markdown renders assistant replies; images/voice add attach/talk buttons

Outputs (write-only; set(...) replaces the value):

Factory (defaults) Write / methods Notes
output({ format? }) set(text) format: "markdown" renders GFM
json() set(value) pretty-printed JSON
log() push(line), await all() append-only lines
label() set(string | { label?, confidences? }) classifier result; confidences: { label, score }[] → bars
html({ value? }) set(markup) raw HTML
image() set(urlOrDataUrl) one image
gallery() set(items), add(item) item: { src, caption? }
audio({ autoplay? }) / video({ autoplay?, loop? }) set(src) URL or data URL
progress({ label? }) set(value, label?) value is 0..1
file() set({ name?, url } | url) offer a download
annotatedImage() set(src, annotations?, colorMap?) Annotation: { label, box?: [x0,y0,x1,y1], mask? }
highlightedText() set(spans, colorMap?) span: { text, label? } (label omitted = plain)
chart({ x, y, kind?, data?, maxHeight? }) await data(), setData(rows), push(point) x = category key; y = key or string[]; kind bar/line/area
frame({ src?, doc?, sandbox?, title? }) load(url), show(doc), clear() iframe; event loaded

Editable or read-only:

Factory (defaults) Events Methods
code({ value?, language?, editable?, wrap? }) changed (string) await value(), set(src), setLanguage(lang). editable: false = viewer; wrap soft-wraps
table({ columns?, rows?, editable?, maxHeight? }) edited ({ row, key, value }) await data(), setRows, setColumns, addRow, setCell. Column: { key, label?, type?, width? }

Custom: widget({ state, view, fold?, behavior? }) builds a widget from scratch — state is its data, view(state, emit) renders it, fold applies events to state.

Layout

widgets is a tree of widget objects (no keys/strings). An array is an implicit col:

knobkit({ widgets: col(photo, row(size, go), caption) });
grid([a, b, c, d], { cols: 2 });
tabs([{ label: "One", content: a }, { label: "Two", content: b }]);
accordion({ label: "Advanced", open: false }, x, y);

Containers are widgets whose state is their arrangement, so a handler can restructure the UI at runtime — panel.add(chart), await panel.remove(sidebar).

Theming

Set on knobkit({ … }), or flip at runtime with setTheme / setDensity:

  • theme"system" (default) | "light" | "dark".
  • density"xs" | "sm" | "md" | "lg" | "xl" (default md) — spacing, control sizes, radii, type.
  • fill: true — full-bleed shell that fills the viewport (for split panes / dashboards) instead of the centered card.

Everything renders from CSS custom properties (--pu-bg, --pu-accent, --pu-gap, the --pu-series-* chart palette, …); theme/density just remap them, so one switch restyles the whole kit (including the code editor, table, and chart). The attributes inherit, so you can scope them to one container; to rebrand, override the tokens in your CSS (e.g. :root { --pu-accent: rebeccapurple }).

Develop

pnpm install
pnpm -F knobkit build   # library + browser client bundle
pnpm -F knobkit test    # vitest
pnpm typecheck          # all packages

See CLAUDE.md for the architecture and how to add a widget.

License

MIT
